Fruit line 06
Passion fruit processing line
Valued for its intense flavor and aroma, passion fruit is ideal for juice, puree and powder. Separating seeds and skin and retaining the aroma are key; the usual combination is cold pulp extraction, aseptic filling and freeze or spray drying.
Capacity 1 t/h 3 t/h 5 t/h configured to your requirement
Products & process
Passion fruit products
One line can be set up for one or several of these products. Tell us which ones you want to make and we configure the equipment to your requirement.
- Passion fruit pureeWith or without seeds
- Passion fruit juiceNFC or reconstituted
- Passion fruit concentrateConcentrated pulp for industry
- Freeze-dried passion fruitWhole or crushed
- Passion fruit powderFor beverages and foods
- Passion fruit wineFermented fruit wine
- Passion fruit vinegarFermented fruit vinegar
- Passion fruit seedsFor oil or direct sale
Process flow
- Reception
- Bubble washing
- Cutting
- Pulp extraction
- Seed / skin separation
- Filtration
- Homogenization
- UHT
- Aseptic filling
- Freeze / spray drying Powder
- Fermentation Wine & vinegar
Main equipment
Passion fruit line equipment
What each machine in the line does, with its typical specification. Values are reference figures and are confirmed in the quotation.
-
Bubble washer
Gentle cleaning
Key specBubbling and spraying
-
Passion fruit cutter
Cuts the fruit in half
Key specContinuous automatic cutting
-
Pulp extractor
Separates the pulp from seeds and skin
Key specLow-speed rotor
-
Seed-skin separator
Removes seeds and skin
Key specWithout breaking the seeds
-
Filtration system
Clarifies or preserves texture
Key specScreen or plate filter
-
Homogenizer
Uniform consistency
Key specHigh pressure, 20–40 MPa
-
UHT sterilizer
Aseptic processing
Key specTube-in-tube, 110–137 °C
-
Freeze dryer
Freeze-dried products
Key specCondenser ≤ −45 °C
-
Spray dryer
Passion fruit powder
Key specInlet 150–200 °C
-
Fermentation tank
Wine and vinegar
Key specJacketed, temperature-controlled
-
Packaging line
Bottles, bags or bulk
Key specAseptic bag, PET or glass
Images are illustrative; specifications are confirmed in the quotation.
Every plant also needs general systems — CIP cleaning, water treatment, cold storage, metal detection, a PLC control panel, a steam boiler and compressed air — plus a packaging line suited to your product. General systems · Packaging lines
Commercial terms
Clear terms, from quotation to commissioning
Every line is quoted for your fruit, products and capacity. These are our standard conditions.
- Price
- FOB / CIFFOB China or CIF to your port
- Delivery
- 30–60 daysAfter order confirmation
- Payment
- T/T or L/CTelegraphic transfer or letter of credit
- Warranty
- 12 monthsFrom commissioning
- Installation
- Remote or on siteRemote support or an engineer at your plant
- Spare parts
- Initial kit includedAn initial spare-parts kit ships with the line
- Panel language
- ES / EN / 中文Spanish, English or Chinese
- Material
- SUS304 / 316LFood-grade stainless steel; 316L for high-acidity products
Technical parameters are typical reference values and are confirmed in the quotation.
FAQ
Questions about the passion fruit line
How are seeds and skin separated without breaking the seeds?
The cutter halves the fruit in a continuous automatic cut; the pulp extractor, with a low-speed rotor, separates the pulp from seeds and skin, and the seed-skin separator removes them without breaking the seeds.
How is passion fruit aroma preserved?
The usual combination is cold pulping, tube-in-tube UHT sterilisation (110–137 °C) with aseptic filling and, for powder, freeze drying (condenser at −45 °C or below) or spray drying (150–200 °C inlet).
What happens to the seeds?
Passion fruit seeds are a product in their own right, used for oil extraction or sold directly. The pulp is sold with or without seeds, and the line also makes NFC or reconstituted juice, concentrate, freeze-dried passion fruit, powder, wine and vinegar.
What capacity can I choose?
The passion fruit line is configured at 1, 3 or 5 t/h, depending on your raw material and production plan. Because the lines are modular, much of the equipment — washing, pulping, heat treatment and packaging — can also run other fruits, so the plant keeps working all year.
How long is delivery, and what is included?
Delivery takes 30–60 days after order confirmation, priced FOB China or CIF your port, with payment by T/T or L/C. The line ships with an initial spare-parts kit, installation is remote or with an engineer at your plant, and the warranty runs 12 months from commissioning.
Request a quote
Tell us which passion fruit products you want to make, and at what capacity
Our modular lines can process several fruits, so your plant can work all year. Tell us what you want to make and at what capacity — 1, 3 or 5 t/h — and we will reply within one business day with the next steps.
