Fruit line 05
Banana & plantain processing line
Banana and plantain become chips, puree, powder, flour, jam, wine, vinegar and canned slices. Both are high in starch and sugar, so for chips the key is controlling browning, oil content and water activity.
Capacity 1 t/h 3 t/h 5 t/h configured to your requirement
Products & process
Banana and plantain products
One line can be set up for one or several of these products. Tell us which ones you want to make and we configure the equipment to your requirement.
- Banana chipsFried or vacuum-fried
- Banana pureeBaby food, beverages, bakery
- Banana powderSpray-dried
- Banana flourResistant starch from green plantain
- Banana jamSweet spread
- Banana wineFermented fruit wine
- Banana vinegarFermented fruit vinegar
- Canned slicesSlices in syrup
Process flow
- Reception
- Peeling
- Slicing
- Color protection
- Vacuum frying / drying
- De-oiling
- Seasoning
- Nitrogen packing
- Pulping Puree / powder
- Fermentation Wine & vinegar
Main equipment
Banana and plantain line equipment
What each machine in the line does, with its typical specification. Values are reference figures and are confirmed in the quotation.
-
Banana peeler
Automatic peeling
Key specSuitable for green plantain
-
Slicer
Uniform slices
Key specAdjustable thickness, 1–5 mm
-
Color protection tank
Prevents browning
Key specImmersion in an antioxidant solution
-
Vacuum fryer
Crunchy, low-oil chips
Key spec80–110 °C under vacuum, plus centrifuging
-
Heat pump dryer
Dehydrated slices
Key spec40–75 °C, energy-saving
-
Pulper
Makes banana puree
Key specInterchangeable screen
-
Homogenizer
Fine-textured puree
Key specHigh pressure, 20–40 MPa
-
Spray dryer
Produces banana powder
Key specInlet 150–200 °C
-
Fermentation tank
Wine and vinegar
Key specJacketed, temperature-controlled
-
Packaging line
Bags, bottles or sachets
Key specWith nitrogen for chips
Images are illustrative; specifications are confirmed in the quotation.
Every plant also needs general systems — CIP cleaning, water treatment, cold storage, metal detection, a PLC control panel, a steam boiler and compressed air — plus a packaging line suited to your product. General systems · Packaging lines
Commercial terms
Clear terms, from quotation to commissioning
Every line is quoted for your fruit, products and capacity. These are our standard conditions.
- Price
- FOB / CIFFOB China or CIF to your port
- Delivery
- 30–60 daysAfter order confirmation
- Payment
- T/T or L/CTelegraphic transfer or letter of credit
- Warranty
- 12 monthsFrom commissioning
- Installation
- Remote or on siteRemote support or an engineer at your plant
- Spare parts
- Initial kit includedAn initial spare-parts kit ships with the line
- Panel language
- ES / EN / 中文Spanish, English or Chinese
- Material
- SUS304 / 316LFood-grade stainless steel; 316L for high-acidity products
Technical parameters are typical reference values and are confirmed in the quotation.
FAQ
Questions about the banana and plantain line
How do you make crisp banana chips with little oil?
Slices are cut evenly (thickness adjustable from 1 to 5 mm), pass through the colour protection tank and are vacuum-fried at 80–110 °C, then centrifuged to remove oil and packed under nitrogen. The critical points are browning, oil content and water activity.
Does the line handle green plantain?
Yes. The peeler is suitable for green plantain, and green plantain is used to make flour rich in resistant starch. For dried slices without frying, the heat pump dryer runs at 40–75 °C.
What other products can the line make?
The pulper (interchangeable screen) and homogeniser (20–40 MPa) produce puree for baby food, drinks and bakery; the spray dryer (150–200 °C inlet) produces banana powder. Fermentation tanks make wine and vinegar, and the line also covers jam and canned slices in syrup.
What capacity can I choose?
The banana and plantain line is configured at 1, 3 or 5 t/h, depending on your raw material and production plan. Because the lines are modular, much of the equipment — washing, pulping, heat treatment and packaging — can also run other fruits, so the plant keeps working all year.
How long is delivery, and what is included?
Delivery takes 30–60 days after order confirmation, priced FOB China or CIF your port, with payment by T/T or L/C. The line ships with an initial spare-parts kit, installation is remote or with an engineer at your plant, and the warranty runs 12 months from commissioning.
Request a quote
Tell us which banana products you want to make, and at what capacity
Our modular lines can process several fruits, so your plant can work all year. Tell us what you want to make and at what capacity — 1, 3 or 5 t/h — and we will reply within one business day with the next steps.
